HELICHECK 3D
For generating 3D point clouds

HELICHECK 3D

Basic Data

The HELICHECK 3D measuring machine generates 3D models of tools and production parts. One completely new technology is the ability to scan tools and comparing the scan to a target model from the customer's CAD/CAM system. It is the easiest and fastest way to scan a tool and then analyze the virtual image of the tool or compare it to the target model. Take advantage of this new tool digitization technology.

Features

3D Scan

With the 3D Scan procedure, tools and workpieces can be scanned very quickly and easily , with their entire geometry registered.

Read more

Solid granite base

A solid granite basis has the weight to deliver precision and accuracy. The granite base dampens vibrations and is thermally stable. These are the prerequisites for very high measurement accuracy and reliable measurement results.

ISO 50 Spindle

The high-precision ISO 50 spindle with automatic clamping mechanism provides precise and repeatable measurements.

Ball roller spindle

High precision ball roller spindles and linear guides guarantee excellent positioning accuracy, which is a prerequisite for precision measurement results.

Hardware / Software
  • Modular adaptor spindle
    Rapid-switch adapters can be exchanged quickly and easily without further setup time. The following quick change adapters are available: ISO/HSK/Capto/VDI.

  • Centre holder
    For tools that for technical reasons must be produced between centres, the high concentricity precision must also be fulfilled during the measurement process. WALTER offers a precise centre holder to ensure that this is satisfied.
Technical Data
kg / cm
lb / inches

Linear Axes

Max. Travel X 270 mm
Max. Travel Y 455 mm
Max. Travel Z 325 mm

Swiveling Axes

Swiveling Range B 120 °

Workpiece Data

Workpiece Length 420 mm
Workpiece Diameter 3 - 80 mm
Max. Workpiece Weight 25 kg

Linear Axes

Max. Travel X 10.63 inch
Max. Travel Y 17.91 inch
Max. Travel Z 12.80 inch

Swiveling Axes

Swiveling Range B 120 deg

Workpiece Data

Workpiece Length 16.53 inch
Workpiece Diameter 0.12 - 3.15 inch
Max. Workpiece Weight 55.12 lbs
